- Place of Origin: China
- Brand Name: hexin
- Model Number: QC12Y
1, the machine for all steel welding, hydraulic transmission, vibration to eliminate stress, high strength, good rigidity machine. Hydraulic pendulum shearing machine is through the adoption of the main oil cylinder fixed on the wall () do downward shearing movement, the nitrogen cylinder return, thus simplify the hydraulic system, running more stable. Pendulum shearing machine of tool carrier on around a fixed axis for circular arc in the process of shear oscillation, leverage, fulcrum force is small, can improve the shear blade life, machine life, the machine has compact structure, and can adjust the tool post stroke volume on the promise, greatly improve the work efficiency.
2, the size and number of shear behind have a digital display device. Upper and lower blade blade gap adjustment by signs indicating, adjust light and quick.
3, the guard interlock life safety device and electric box.
4, the use of advanced integrated hydraulic system, good reliability.
Hydraulic sheet metal bending machine structure and using method
Adopted the electromagnetic clamping, making the pressure plate can be made into a variety of workpiece, but also to have a wall of workpiece processing.
- Place of Origin: China
- Brand Name: hexin
- Model Number: QC12Y
model | thickness(mm) | wide(mm) | shear angle | Strength of materials(N/mm) | adjusting range(mm) | Travel times (time/min) | Main motor power(Kw) | weight | Overall dimensions |
QC12Y-4×2500 | 4 | 2500 | 1°30′ | ≤450 | 20-500 | 16 | 5.5 | 5000 | 3040×1610×1620 |
QC12Y-4×320 | 4 | 3200 | 1°30′ | ≤450 | 20-500 | 13 | 5.5 | 6000 | 3840×1610×1620 |
QC12Y-6×2500 | 6 | 2500 | 1°30′ | ≤450 | 20-500 | 15 | 7.5 | 6000 | 3040×1610×1620 |
QC12Y-6×3200 | 6 | 3200 | 1°30′ | ≤450 | 20-500 | 12 | 7.5 | 7000 | 3840×1610×1620 |
QC12Y-6×4000 | 6 | 4000 | 1°30′ | ≤450 | 20-600 | 9 | 7.5 | 8300 | 4620×1750×1700 |
QC12Y-6×6000 | 6 | 6000 | 1°30′ | ≤450 | 20-800 | 5 | 18.5 | 18500 | 6480×2100×2300 |
QC12Y-8×2500 | 8 | 2500 | 1°30′ | ≤450 | 20-500 | 14 | 7.5 | 7000 | 3040×1700×1700 |
QC12Y-8×3200 | 8 | 3200 | 1°30′ | ≤450 | 20-500 | 8 | 7.5 | 7500 | 3860×1700×1700 |
QC12Y-8×4000 | 8 | 4000 | 1°30′ | ≤450 | 20-600 | 8 | 11 | 8500 | 4640×1700×1700 |
QC12Y-8×6000 | 8 | 4000 | 1°30′ | ≤450 | 20-800 | 8 | 18.5 | 20000 | 6480×2100×2350 |
QC12Y-10×2500 | 10 | 2500 | 1°30′ | ≤450 | 20-500 | 10 | 7.5 | 7300 | 3040×1700×1700 |
QC12Y-10×3200 | 10 | 3200 | 2° | ≤450 | 20-500 | 10 | 7.5 | 8000 | 3860×1700×1700 |
QC12Y-10×4000 | 10 | 4000 | 2° | ≤450 | 20-600 | 10 | 18.5 | 12050 | 4650×2100×2000 |
QC12Y-10×6000 | 10 | 6000 | 1°30′ | ≤450 | 20-600 | 10 | 18.5 | 24000 | 6500×2100×2300 |
QC12Y-12×2500 | 12 | 2500 | 1°40′ | ≤450 | 20-500 | 12 | 18.5 | 11000 | 3140×2150×2000 |
QC12Y-12×3200 | 12 | 3200 | 1°40′ | ≤450 | 20-500 | 10 | 18.5 | 12500 | 3880×2150×2000 |
QC12Y-12×4000 | 12 | 4000 | 1°40′ | ≤450 | 20-600 | 10 | 18.5 | 14500 | 4680×2150×2000 |
QC12Y-16×2500 | 16 | 2500 | 2° | ≤450 | 20-500 | 10 | 18.5 | 12000 | 3140×2150×2000 |
QC12Y-16×3200 | 16 | 3200 | 2° | ≤450 | 20-600 | 10 | 18.5 | 13500 | 3880×2150×2000 |
QC12Y-16×4000 | 16 | 4000 | 2°30′ | ≤450 | 20-800 | 10 | 18.5 | 16000 | 4650×2150×2200 |
QC12Y-20×2500 | 20 | 2500 | 2°30′ | ≤450 | 20-500 | 8 | 37 | 18000 | 3440×2300×2500 |
QC12Y-20×3200 | 20 | 3200 | 2°30′ | ≤450 | 20-1000 | 8 | 37 | 23000 | 4150×2350×2700 |
QC12Y-25×2500 | 25 | 2500 | 3° | ≤450 | 20-1000 | 8 | 45 | 25000 | 3200×2700×2900 |
QC12Y-25×3200 | 25 | 3200 | 3° | ≤450 | 20-1000 | 5 | 37 | 26000 | 4200×2500×2600 |
QC12Y-30×2500 | 30 | 2500 | 3° | ≤450 | 20-1000 | 4 | 40 | 28000 | 3300×2900×3000 |
QC12Y-30×3200 | 30 | 3200 | 3°30′ | ≤450 | 20-1000 | 4 | 40 | 34000 | 4200×2500×2600 |
QC12Y-40×2500 | 40 | 2500 | 4° | ≤450 | 20-1000 | 3 | 75 | 46000 | 3200×3300×3200 |
QC12Y-40×3200 | 40 | 3200 | 4° | ≤450 | 20-1000 | 3 | 90 | 58000 | 4300×3300×3000 |
